R452A
2 ÷ 11 kW
| Code | Model | Power supply
V/ph/Hz |
Minimum cooling temperature
W* |
Maximum cooling temperature
W* |
|---|---|---|---|---|
| 999920000 | G1A 11N | 400/3+N/50 | 2112 | 10588 |
0.7 ÷ 4 kW
| Code | Model | Power supply
V/ph/Hz |
Minimum cooling temperature
W* |
Maximum cooling temperature
W* |
|---|---|---|---|---|
| 999920030 | G1A 4,5B | 400/3+N/50 | 728 | 4220 |
1 ÷ 6.5 kW
0.7 ÷ 2 kW
| Code | Model | Power supply
V/ph/Hz |
Minimum cooling temperature TN W* |
Maximum cooling temperature TN W* |
Minimum cooling temperature BT W* |
Maximum cooling temperature BT W* |
|---|---|---|---|---|---|---|
| 999920059 | G1A 2N 1,2B | 400/3+N/50 | 1013 | 2003 | 646 | 1278 |
| 999920060 | G1A 4N 1,5B | 400/3+N/50 | 2112 | 4177 | 728 | 1441 |
| 999920061 | G1A 6,5N 2B | 400/3+N/50 | 3242 | 6411 | 980 | 1939 |
Calculations Conditions:
* TN= – 10°C / + 45°C
BT= – 30°C / + 45°C
